Features
- Combined internal and external cleaning
- Integrated detergent set (up to 4 media tanks)
- Positive internal keg transport
- Completely piped and wired
- Limited time for installation/commissioning: connect and run
- Integrated control cabinet with 15" HMI color display showing process/alarm graphics
- PLC with touchscreen control
- Transport in standard container
- Small footprint
- Remote service and diagnostic system
- Safety perimeter by glass panels
- Foam cleaning ready
- 2 to 4 active washing heads
- 1 filling head with auto shut off control
Technical data
- Capacity 50-60 kph (depending on configuration and keg size)
- 10 till 60 l kegs, dia 235-430 mm, H 300 to 620 mm
- Filling accuracy ± 1,25 % ( - ± 0,2% with BPCU)
- CO2 loss - 0,0-0,1 g/l
- O2 pick up - 0,08 ppm ( / 0,05 ppm with BPCU)
- Noise level < 80 dbA - dimensions: L 3375 mm x W 1700 mm x H 2510 mm production (H 2200 transport)
- Weight: empty 2300 kg / production 2750 kg
- Power 230/400 V - 50/60 Hz - 4-12 kW (depending on configuration)
- Shipping form: one 20’ container = 1 TEU
Options
- Automatic detergent dosing system
- Flow meter with automatic back pressure control unit (BPCU)
- Auxiliary machines (weigher, turner,
coder, keg conveying, palletizing)
- integrated weighing scale
General
- 2 washing heads
- 1 filling head
- 2 detergent tanks (in option to 4)
- 2 m driven in feed conveyor / 2 m gravity out feed conveyor
- Completely piped and wired
- Safety perimeter glass panels
- Small footprint design on SS-frame
